Model #:
RGV3-486GD-L
Color:
Stainless Steel
48" Series 7 Professional 6 Burner with Griddle Gas Range, LPG
48" Series 7 Professional 6 Burner with Griddle Gas Range, LPG
Dimensions
Width: 47 7/8
Height: 35 3/4 - 36 3/4
Depth: 29 1/8
Color
Stainless Steel
Features
- Featuring a generous total capacity of 7.7 cu ft, with enough room to fit a 32 lb turkey. The griddle plate allows you to cook several foods at once.
- Sealed Dual Flow Burners™ deliver cooktop power up to 17,000 BTU for seriously fast boiling right down to a precise 140°F full surface simmer with the gentlest of flames.
- The cooktop is designed for easy access to any burner with grates you can smoothly slide pots across. The oven is large enough to hold full size baking sheets.
- This range has craftsmanship in every detail, with real stainless steel, cast-iron trivets, and titanium coated dials. Each cavity features incandescent lights and full extension telescopic racks. From the robust legs to the powerful legs to the powerful cooktop, the Range is built to last.
- Cleaning up spills is effortless with the continuous, porcelain basepan. Your cooktop simply needs a quick wipe to keep it looking good as new.
- Precise control across high and low settings is delivered through the halo-illuminated cooktop dials.
- Precise control across high and low settings is delivered through the halo-illuminated cooktop dials.
Product Description
With Professional styling, this large range has six burners delivering powerful high heat, a griddle and two gas ovens.
Rebates
Specification
| 3/4 Extension racks | |
| 3/4 Extension racks | 2 |
| ADA compliant | |
| ADA compliant | true |
| Auto re-ignition system | |
| Auto re-ignition system | true |
| Bake | |
| Bake | true |
| Bake power | |
| Bake power | 19700BTU |
| Broil | |
| Broil | true |
| Broil | 18500 BTU |
| Broil pan | |
| Broil pan | true |
| Combustible situation | |
| Combustible situation | BGRV3-3048H |
| Connection | |
| Connection | 3-prong grounding type plug |
| Convection bake | |
| Convection bake | true |
| Depth | |
| Depth | 29 1/8" |
| Easy clean porcelain basepan | |
| Easy clean porcelain basepan | true |
| Electronic oven control | |
| Electronic oven control | true |
| Fitting and pipe | |
| Fitting and pipe | ½ NPT, min. ?" Ø flex line |
| Full extension telescopic sliding shelves | |
| Full extension telescopic sliding shelves | true |
| Height | |
| Height | 35 3/4 - 36 3/4" |
| Infrared Broiler | |
| Infrared Broiler | true |
| Internal light | |
| Internal light | true |
| Maximum burner power | |
| Maximum burner power | 17000 BTU |
| Metal illuminated dials | |
| Metal illuminated dials | true |
| Non combustible situation | |
| Non combustible situation | BGRV2-3048 / BGRV2-1248 |
| Number of functions | |
| Number of functions | 4 |
| Number of secondary oven functions | |
| Number of secondary oven functions | 4 |
| Parts and labor | |
| Parts and labor | Limited 2 years |
| Power back centre | |
| Power back centre | 13000BTU |
| Power back left | |
| Power back left | 13000BTU |
| Power back right | |
| Power back right | 13000BTU |
| Power front centre | |
| Power front centre | 15000BTU |
| Power front left | |
| Power front left | 17000BTU |
| Power front right | |
| Power front right | 15000BTU |
| Power griddle | |
| Power griddle | 15000BTU |
| Power supply | |
| Power supply | 120 V, 60 Hz |
| Proof | |
| Proof | true |
| Recommended hood | |
| Recommended hood | HCB48-12_N (48" Professional Range Hood, Dual Blower) |
| Sealed range top | |
| Sealed range top | true |
| Secondary oven - Bake power | |
| Secondary oven - Bake power | 18000BTU |
| Service | |
| Service | 15 A |
| Shelf positions (main oven) | |
| Shelf positions (main oven) | 5 |
| Shelf positions (second oven) | |
| Shelf positions (second oven) | 5 |
| Slow cook | |
| Slow cook | true |
| Supply Pressure (LPG) | |
| Supply Pressure (LPG) | 11" to 14" W.C |
| Total capacity (main oven) | |
| Total capacity (main oven) | 5.3cu ft |
| Total capacity second oven | |
| Total capacity second oven | 2.4cu ft |
| Total cooktop power | |
| Total cooktop power | 101000 BTU |
| Usable capacity (main oven) | |
| Usable capacity (main oven) | 3.9cu ft |
| Vent trim included | |
| Vent trim included | true |
| Width | |
| Width | 47 7/8" |
Documentation
From the Manufacturer
Warranty
We offer 1 year manufacturers warranty and a 10-year major component warranty.
OUR SERVICES ARE PROVIDED ON AN "AS IS" AND "AS AVAILABLE" BASIS. YOU EXPRESSLY AGREE THAT USE OF ANY SERVICE OFFERED BY US IS AT YOUR SOLE RISK. TO THE FULLEST EXTENT PERMISSIBLE PURSUANT TO APPLICABLE LAW, WE DISCLAIM ALL WARRANTIES OF ANY KIND, WHETHER EXPRESS OR IMPLIED, INCLUDING WITHOUT LIMITATION ANY WARRANTY OF MERCHANTABLITY, FITNESS FOR A PARTICULAR PURPOSE OR NON-INFRINGEMENT. WE DO NOT MAKE ANY WARRANTY THAT OUR SERVICE WILL MEET YOUR REQUIREMENTS, OR THAT ANY SERVICE OFFERED BY US WILL BE UNINTERRUPTED, TIMELY, SECURE, OR ERROR FREE, OR THAT DEFECTS, IF ANY, WILL BE CORRECTED; NOR DO WE MAKE ANY WARRANTY AS TO THE RESULTS THAT MAY BE OBTAINED FROM THE USE OF ANY SERVICE OFFERED BY US OR AS TO THE ACCURACY OR RELIABILITY OF ANY INFORMATION OBTAINED THROUGH ANY SERVICE OFFERED BY US. YOU UNDERSTAND AND AGREE THAT ANY MATERIAL AND/OR DATA DOWNLOADED OR OTHERWISE OBTAINED THROUGH THE USE OF ANY SERVICE OFFERED BY US IS AT YOUR OWN DISCRETION AND RISK, AND THAT YOU WILL BE SOLELY RESPONSIBLE FOR ANY DAMAGE TO YOUR COMPUTER SYSTEM OR LOSS OF DATA THAT RESULTS FROM THE DOWNLOAD OF SUCH MATERIAL AND/OR DATA. WE DO NOT MAKE ANY WARRANTY REGARDING ANY GOODS OR SERVICES PURCHASED OR OBTAINED THROUGH US OR FROM ANY SERVICE OFFERED BY US OR ANY TRANSACTIONS ENTERED INTO BY USE OF OR THROUGH ANY SERVICE OFFERED BY US. NO ADVICE OR INFORMATION, WHETHER ORAL OR WRITTEN, OBTAINED BY YOU FROM US, OR THROUGH ANY SERVICE OFFERED BY US, SHALL CREATE ANY WARRANTY NOT EXPRESSLY MADE HEREIN. SOME JURISDICTIONS DO NOT ALLOW THE EXCLUSION OF CERTAIN WARRANTIES, SO SOME OF THE ABOVE EXCLUSIONS MAY NOT APPLY TO YOU.
PRODUCT INFORMATION AND DESCRIPTIONS -- WE ATTEMPT TO BE AS ACCURATE AS POSSIBLE. WE DO NOT WARRANT THAT PRODUCT DESCRIPTIONS, SPECIFICATIONS OR OTHER CONTENT OF THIS SITE ARE ERROR FREE, ACCURATE, COMPLETE, RELIABLE, OR CURRENT. IF A PRODUCT OFFERED OR SOLD BY US IS NOT AS DESCRIBED, YOUR SOLE REMEDY IS TO RETURN IT IN UNUSED CONDITION IN ACCORDANCE WITH OUR RETURN POLICY.
Delivery
Let our team co-ordinate professional delivery and installation on your new purchase. Some restrictions may apply.
Disclosures
Proposition 65 Warning for California ResidentsCancer and Reproductive Harm - P65Warnings.ca.gov
Brand Restrictions
There may be a brand exclusion with this product that only allows us to sell it within so many miles of our store. Please contact us with any questions you may have.
With Professional styling, this large range has six burners delivering powerful high heat, a griddle and two gas ovens.
